BK1000 Series Biological Microscope
CE
|
Total
magnifications ..............................40X-1600X
Eyepiece
..................................................WF10X
Achromatic objectives
..........4/0.10 10/0.25 40/0.65
........................................................
100/1.25(Oil)
Condenser ................................................NA1.25
Coaxial coarse and fine focusing
adjustment knobs
Base
....Built in 6V 20W halogen bulb with adjustable
brightness
Optional accessories
1) Eyepieces .....................WF16X WF10X (article
)
2) Photo eyepiece ..........................S2.5X S4X
6.3X
3) S-Plan achromatic objectives
........................ 4/0.10 10/0.25 40/0.65
100/1.25(Oil)
4) Plan achromatic objectives
.............. 4/0.10 10/0.25 25/0.4 40/0.65
100/1.25(Oil)
5) Dark field attachment.............Dark field
condenser
6) Simple polarizer attachment ...........Polarizer
slide
........................................................Analyzer
slide
7) Phase contrast attachment
8) 35mm photo attachment
9) C-Mount and CCD camera |
|
|
