H6000 Series Biological Microscope
CE
|
Total
magnifications ............................40X-1600X
Eyepiece
...............................................WF 10X
S-plan achromatic objectives
...SP10/0.25 SP25/0.40 SP40/0.65 SP100/1.25 (Oil)
Plan achromatic objectives
.... PL10/0.25 PL25/0.40 PL40/0.65 PL100/1.25 (Oil)
Condenser
..............................................NA1.25
Base ...Revolving switch
Built in 6V 20W halogen lamp with adjustable
brightness
Optional accessories
1) Eyepieces..................... WF10X(Pointer) WF16X
2) Heads ........................Seidentopf binocular
head
......................................Seidentopf
trinocular head
............................................Sliding
binocular head
........................................... Sliding
trinocular head
3) Plan achromatic objective
.....................PL4/0.10
4) Phase contrast attachment
5) Dark field attachment
....................... Dark field condenser
(N.A.0.83-0.91)
6) Polarizer attachment .....................Polarizer
slide
.......................................................
Analyzer slide
7) 35mm photo attachment
..10X reticule eyepiece S2.5X S4X S6.3X photo
eyepieces
8) C-Mount and CCD camera
9) Fluorescence attachment
....................Incident fluorescence illuminator
(B, G)
.........Incident fluorescence illuminator (B, G, V,
UV)
..DC 100W mercury lamp house (220V 50HZ/110V 60HZ)
..AC 200W mercury lamp house (220V 50HZ)
10) Fluorescence objectives .......25/0.65 40/1 (Glyc)
......................................................
100/1.25(Glyc)
11) Side viewing attachment
.................................. Two view field
space 600mm |
|
|
