BK2000 Series Biological Microscope
CE
|
กก
Total
magnifications
............................40X-1600X
Eyepiece
................................................WF10X
S-Plan achromatic objectives
..................... 4/0.10 10/0.25 40/0.65
100/1.25(Oil)
Condenser
...........................................N.A. 1.25
Coaxial coarse and fine focusing
adjustment knobs
Base
Built in 6V 20W halogen bulb with adjustable
brightness
Optional accessories
1) Eyepieces .......WF16X WF10X(pointer)
WF10X(reticle)
2) Photo
eyepieces..................................S2.5 S4
3) Phase contrast attachment
4) 35mm photo attachment
5) C-Mount and CCD camera
6) Simple polarizer attachment ........Polarizer slide
.....................................................Analyzer
slide
7) Dark field attachment .........Dark field condenser |
|
|
